SUNBA – Dedicated Pan Tilt Zoom Solution Provider | Model 601-D25X Built-in Mic 5MP Version
Features
- 5 MegaPixel (2560x1960p) @20fps, 1080p@30fps, Sony IMX 307 Starvis CMOS
- Comes with 25x optical zoom
- High speed pan tilt zoom with 360 degrees endless horizontal rotation, 15 degrees upward tilt and 90 degrees downward movement
- Long range infrared LED night vision up to 1000ft (IEC-60825-1 approved)
- Compatible with Blue Iris, QNAP and Security Spy (Mac)
- Built-in mic
- H.265 efficient decoding for reduced bandwidth and storage space when recording to Blue Iris, Sunba VMS and Sunba H.265 NVR
- Power over Ethernet; Important: PoE+(802.3at) required with at least 25W output.
Setup
601-D25X is shipped under DHCP now and can be setup using iSunba app (only when you connect to the same network as smartphone). End-users can modify to static IP with VMS/IE/Device Manager tool, and later use Sunba VMS or any compatible 3rd party software/app for live view & control.
What’s Included
Manual, Camera, Wall Bracket and a complementary 12V4A Power Adapter (the PoE adapter is not included)
Exceptional Pan Tilt Zoom Capacity
- High speed PTZ 0~120°/s;
- 360 all-frame endless rotation;
- 15 degrees upward tilt;
- Outdoor IP 66 Rated Waterproof.
- Support presets and 4 groups of patrol around your property.
Power Over Ethernet (network and power in one cable)
Attention: PoE+ injector/switch required (802.3at) 25W;
Conventional PoE (802.3af) only delivers 15.4W and will cause underpower!
Power Standard
1. 25W 802.3at Standard (with PoE+ solution);
2. 12VDC 4A (if using the optional power adapter). Higher voltage will damage the unit.
Optional WiFi Connection
The camera has a built-in module to provide users with a convenient installation method (no Ethernet cable is needed).
Attention:
- The camera only works with 2.4GHz WiFi, 5GHz or other WiFi network is not supported.
- The camera is not battery powered, it should be powered by a DC12V adapter (comes with the camera by default).
- If the WiFi signal is too weak, the connection will be unstable.
25X Optical Zoom
The 5MP SONY CMOS provides crystal clear details on the image. With 25X optical zoom (focal length: 4.8mm~120mm), you are equipped with eagle eyes that capture activities hundreds miles away.
Night Vision up to 1000ft
Your property will be covered by the superior night vision of Sunba 601-D25X with 10 pieces of IR LED. The infrared illumination distance can reach up to 1000ft depending on the scene. The 25X PTZ has a right array of low beam IR LED (for 1~12x) and a left array of high beam LED illuminating further objects at 13x~25x zoom level.
Remote View
Remotely watch live view, and control PTZ/Preset of the camera through XMEye app (iOS & Android) with motion detection snapshot stored in cloud server.
Cloud platform registration required to enable push notification.
